유리를 통해 80 인치;대화 형 6 점 터치 포일 필름, 멀티 터치 포일 유리, USB 인터페이스와 빠른 배달
    판매가격 : 4,027,200 원
    상품번호 :105413
    해외배송 : 국제항공운송비 무료적용상품
    적립금액 :배송완료후 2%적립 [후기작성시 1%추가적립]
    상품상태 :신상품
    원산지명 :중국
    제조업체 :by OEM
    브랜드명 :OEM [브랜드바로가기]
    구매수량 :
    총 금액 :



    * 위의 탭에서 언어를 선택하시면 원본 또는 번역된 내용을 보실수 있습니다.*
                 inch         =  cm               파운드(lb)  =  킬로그램(kg)

    상품상세정보/Okzzim

    Brand Name:
    Xintai Touch
    Style:
    Electric
    Portable:
    Yes
    Format:
    16:9
    Screen Type:
    Portable Screen
    Model Number:
    XT-TF80-6
    Material:
    projective capacitive touch foil
    Detection Method:
    Projected Capacitance technology using horizontal vertical wires
    Screen Sizes:
    From: 15" To 120" . Available in 4: 3 & 16: 9 format.
    Position accuracy:
    Approximately 3 mm absolute, 1 mm relative. No drift
    Alignment:
    Software drivers provide a calibration facility
    Sensitivity::
    Functions with non-mertalise, single construction glass 16mm thick.
    Speed of response::
    Depends upon glass thickness. Typically 50 to 100ms.
    Output::
    USB Port
    Software Compatibility::
    Windows XP & Vista. Windows7 windows8 Android,Linux,MAC
    Temperature range::
    Better than -10 to +70
    Item:
    touch foil

    상품설명/번역이 필요하시면 고객센터(070-8748-4219)로 연락주세요./번역이 필요하신경우 고객센터(070-8748-4219)로 연락주세요.

    80" Interactive 6 points touch foil Film through glass,Multi Touch Foil Glass, fast delivery with USB interface



    Capacitive Touch Foil Working Principal

    interactive touch foil will Quickly enable a touch screen in your ordinary glass world. 's large format flexible touch panel, cover from 30 to has 3 key parts. 1st is film sensor, 2nd is electronics controller, we call it eBoard, 3rd is driver. Film sensor is a green technology product, has high transparency, light and thin. the embedded nano wire grid is a sensor network, that can precisely positioning hands touch action. It use sensing technology, easily change an to bullet­proof touch screen. eBoard use SoC architecture, so the PCB is small and strong noise filtering algorithm, It can detect weak signal that caused by hands.



    Driver support Windows XP/7/8, include 32 bit and 64 bit. sion, Mac OSX, Android 4.0 up version.

    It has two version, one is cling film version, it designed for interactive window and could be peeledoff for reusing. Another is permanent version, once you peel off the cover layer and laminate onto the glass, the sensor will be permanently fixed.





    Super advantages for 80 inch 6 points capacitive touch foil :

    1. Projected Capacitance Touch Foil Technology
    2. Works on glass up to 20mmthickness
    3. Easy to use or install, and Simple to set up for touch foil
    4. Durable flexible touch foil, very light and thin touch foil
    5. Perfect 6-point-touch, Quick touch response speed
    6. Fixing options: removable and permanent, Can be permanent or replaceable
    7. Can be attached to almost every surface: Shop window, Glass, Acrylic and Rear projection film and any other non-metallic material
    8. Available Size: from 30 to 180 inches sheets, bigger available on request



    The Interactive Touch Foil 상세정보
    Safety and robust
    Anti­scratch, laminate on the back of
    Waterproof, dust­proof, bullet­proof,
    No expose components, safety.
    No mechanical components with long life
    Industrial temperature range: -20 °C to +


    Art and Sci­Fi
    High transparency ≥93%, glass­level transparency
    No bezel of touch area
    Thin and light, the sensor thickness only 0.17mm
    Thru­glass touch, the maximum thickness of glass can reach 20mm.
    Only hands valid, no touch action of metal, plastic, and so on.


    Excellent experience
    Zero pressure touch, even with glove.
    Mouse function with Zoom in/out and rotation.
    2 points Multi­touch, Support TUIO & Win Native
    Precise touch & real­time response


    Advanced features
    Low power consumption, the maximu consumption is only 0.5w
    Flexible, could be applied to curve surface screen
    The film sensor could be laminated on any smooth non­metallic flat
    Various size from 17" to 100", lowest cost customization.

    laminate on the back of glass
    waterproof, Acid­proof
    long life
    0 °C to +80 °C level
    Thin and light, the sensor thickness only 0.17mm
    glass touch, the maximum thickness of glass
    nly hands valid, no touch action of metal, plastic,
    Zero pressure touch, even with glove.
    Mouse function with Zoom in/out and rotation.
    touch, Support TUIO & Win Native


    minimum power
    Flexible, could be applied to curve surface touch
    The film sensor could be laminated on any smooth
    0", lowest cost



    Interactive touch foil more specification:



      Induction method

      The improved projected sensing technology, criss-cross X, Y nanowires constitute sensing matrix

     Touch size

      17"~120" can be customized

     Touch accuracy

      No drift, the deviation is about 1~3mm

     Calibration way

      software calibration

     Induction thickness (penetration)

      Adjusted by software to adapt to various thickness of glass, even wear gloves to produce touch-sensitive, can penetrate non-metallic materials about the thickness of 20 mm (middle to allow air layer), the induction can even penetrate glass thickness aboutof 25mm

     Scanning frequency

      60Hz~130hz

     Output way

      USB 2.0 (HID public interface to USB Mini B interface)

     Compatibility system

     WIN7 /WIN8 /Linux (Ubuntu 12.04.4,kernel version:3.11.0-15-generic) / Android4.2 or above ( kernel veersion>A20->3.3.0,RK3188->3.0.36) etc.

     Temperature range

      -20°C~60°C

     Humidity range

      0% RH to 95% RH (without condensation neighborhood)

     Transmittance

      >93%

     Power consumption

      Max 0.5W

     Product Certification

      CE,FCC,ROHS

     EMC

      EN61000-6-1:2007   EN61000-6-3:2007+A1:2011



    aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()



    상품패키지안내/옵션입력창이 없는경우 메모란에 기재하세요.

    Unit Type:
    piece
    Package Weight:
    15.000kg (33.07lb.)
    Package Size:
    60cm x 33cm x 7cm (23.62in x 12.99in x 2.76in)
